Model Parameters |
Name |
C1C 720p |
C1C 1080p |
Model |
CS-C1C-D0-1D1WFR |
CS-C1C-D0-1D2WFR |
Camera |
Image Sensor |
1/4" Progressive Scan CMOS |
1/2.9" Progressive Scan CMOS |
Shutter Speed |
Self-adaptive shutter |
Self-adaptive shutter |
Lens |
2.8mm, view angle:92° (Horizontal), 110°(Diagonal) |
2.8mm, view angle:106° (Horizontal), 130°(Diagonal) |
Lens Mount |
M12 |
M12 |
Day & Night |
IR-cut filter with auto-switching |
IR-cut filter with auto-switching |
DNR |
3D DNR |
3D DNR |
Image |
Max. Resolution |
1280 x 720 |
1920 x 1080 |
Frame Rate |
Max:20fps; Self-adaptive during network transmission |
Max:20fps; Self-adaptive during network transmission |
Compression |
Video Compression |
H.264 |
H.264 |
H.264 Type |
Main profile |
Main profile |
Video Bit Rate |
HD; Standard; Basic. Adaptive bit rate |
Ultra-HD; HD; Standard. Adaptive bit rate |
Auto Bit Rate |
Self-adaptive |
Self-adaptive |
Max. Bitrate |
2Mbps |
2Mbps |
Network |
Smart Alarm |
Motion detection |
Motion detection |
Wi-Fi Pairing |
AP pairing |
AP pairing |
Protocol |
EZVIZ cloud proprietary protocol |
EZVIZ cloud proprietary protocol |
Interface Protocol |
EZVIZ cloud proprietary protocol |
EZVIZ cloud proprietary protocol |
General Features |
Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark |
Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark |
Interface |
Storage |
Support Micro SD card (Max. 256G) |
Support Micro SD card (Max. 256G) |
Power |
Micro USB |
Micro USB |
Wi-Fi |
Standard |
IEEE802.11b, 802.11g, 802.11n |
IEEE802.11b, 802.11g, 802.11n |
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth |
Supports 20MHz |
Supports 20MHz |
Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
Transmission Rate |
11b: 11Mbps, 11g: 54Mbps, 11n: 72Mbpss |
11b: 11Mbps, 11g: 54Mbps, 11n: 72Mbpss |
General |
Requirements |
- 10 - 45°C (14 - 113°F) Humidity 95% or less (non-condensing) |
- 10 - 45°C (14 - 113°F) Humidity 95% or less (non-condensing) |
Power Supply |
DC 5V±10% |
DC 5V±10% |
Power Consumption |
Max. 4.0W |
Max. 4.0W |
IR Range |
Max. 12 meters |
Max. 12 meters |
Product Dimensions |
64mm x 64mm x 103mm |
64mm x 64mm x 103mm |
Packaging Dimensions |
123mm x 79mm x 125.5mm |
123mm x 79mm x 125.5mm |
Weight |
96g |
96g |
