| Model |
DS-2CD5A26G1-IZS |
| Camera |
| Image Sensor |
1/1.8 inch Progressive Scan CMOS |
| Min. Illumination |
Color: 0.002 Lux @ (F1.2, AGC ON), 0.004 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| Day & Night |
IR Cut Filter |
| WDR |
140dB |
| Angle Adjustment |
Pan: 0°to 355°, tilt: 0°to 90°, rotate: 0°to 360° |
| Lens |
| Lens Type |
Motorized lens, 8 to 32 mm |
| Aperture |
8 to 32 mm @ F1.6, Constant F1.6 throughout the zoom range |
| Focus |
Auto, semi-auto, manual |
| FOV |
Horizontal FOV 42.5°to 13.4°, vertical FOV 23.4°to 7.7°, diagonal FOV 49°to 15.3° |
| Lens Mount |
Integrated |
| Compression Standard |
| Video Compression |
H.265, H.265+, H.264, H.264+ |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM |
| Image |
| Max. Resolution |
1920 x 1080 |
| Image Enhancement |
BLC, HLC, Defog, EIS, Distortion Correction, 3D DNR |
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser |
| Day/Night Switch |
Auto/Schedule/Day/Night/Triggered by Alarm In |
| Target Cropping |
Yes |
| Network |
| Network Storage |
microSD/SDHC/SDXC card (256 G), local storage and NAS (NFS, SMB/CIFS), ANR |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| General Function |
One-key Reset, Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark, IP Address Filter |
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Simultaneous Live View |
Up to 20 channels |
| Interface |
| Communication |
1 RJ45 10M/100M/1000M self-adaptive Ethernet port, RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| Audio |
1 input (line in), 1 output (line out), 3.5 mm connector, mono |
| Alarm |
2 inputs, 2 outputs (24 VAC/VDC, 1 A max.) |
| On-board storage |
Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Smart Feature-set |
| Behavior Analysis |
Line crossing detection, intrusion detection, Region entrance detection, Region exiting detection, unattended baggage detection, object removal Detection, Face detection, Scene change detection, audio exception detection, defocus detection |
| Basic Event |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Region of Interest |
4 fixed regions for main stream, sub stream, third stream, fourth stream, and fifth stream, and dynamic face tracking |
| General |
| Power Supply |
12 VDC ± 20%, three-core terminal block, reverse polarity protection PoE (802.3at, class 4) |
| Material |
Metal |
| Impact Protection |
IK10 |
| Weather Proof |
IP67 |
| IR Range |
100m |
| Dimensions |
Φ144 × 347 mm |
| Weight |
1.85kg |
