| Camera |
| Image Sensor: |
|
1/2.8" HD progressive scan CMOS |
| Effective Pixels: |
|
1920(H)x1080(V) |
| Signal System: |
|
PAL/NTSC |
| Minimum Illumination: |
|
Color: 0.005 Lux @(F1.6, AGC ON) B/W: 0.001Lux @(F1.6, AGC ON) 0 Lux with IR |
| White Balance: |
|
Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| AGC: |
|
Auto/Manual |
| BLC: |
|
ON/OFF |
| HLC: |
|
Support |
| Smart defog: |
|
Support |
| WDR: |
|
120dB |
| Shutter Time: |
|
1-1/10,000s |
| Day& Night: |
|
ICR |
| Digital Zoom: |
|
16X |
| Privacy Masking: |
|
24 privacy masks programmable; optional multiple colors and mosaics |
| Auto Focus: |
|
Auto / Semi-automatic / Manual |
| Lens |
| Focal Length: |
|
4.8 mm to 120 mm, 25× optical zoom |
| Zoom Speed: |
|
Approx. 3.6 s (optical lens, wide-tele) |
| Angle of View: |
|
Horizontal field of view: 57.6° to 2.5° (Wide-Tele) Vertical field of view: 34.4° to 1.4° (Wide-Tele) Diagonal field of view: 64.5° to 2.9° (Wide-Tele) |
| Minimum Working Distance: |
|
10-1,500mm(Wide-Tele) |
| Aperture Range: |
|
F1.6 to F3.5 |
| Pan & Tilt |
| Pan Range: |
|
360°endless |
| Pan Speed: |
|
Configurable, from 0.1°/s to 120°/s Preset speed: 120°/s |
| Tilt Range: |
|
-15°-90° (Auto Flip ) |
| Tilt Speed: |
|
Configurable, from 0.1°/s to 80°/s Preset Speed: 80°/s |
| Proportional Zoom: |
|
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: |
|
300 |
| Patrol: |
|
8 patrols, up to 32 presets per patrol |
| Pattern: |
|
4 pattern scans, record time over 10 minutes for each scan |
| Power-off Memory: |
|
Support |
| Park Action: |
|
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan |
| PTZ Position Display: |
|
ON/OFF |
| Infrared |
| IR irradiation distance: |
|
150m |
| IR irradiation angle: |
|
Adjustable by zoom |
| Network |
| Ethernet: |
|
10Base -T, /100Base-TX, RJ45 Connector |
| Max.Image Resolution: |
|
1920×1080 |
| Main Stream: |
|
50Hz:25fps (1920×1080,1280×960,1280×720), 50fps (1280×960,1280×720) ; 60Hz:30fps(1920×1080,1280×960,1280×720), 60fps (1280×960,1280×720) |
| Sub Stream: |
|
50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240) |
| Third Stream: |
|
50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288) 60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288) |
| Video Compression: |
|
Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264/MJPEG Third Stream: H.265/H.264/MJPEG |
| ROI encoding: |
|
Support 4 areas with adjustable levels |
| Audio Compression: |
|
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
| Audio Mode: |
|
OFF/Audio input/Audio output |
| Protocols: |
|
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| No. of Simultaneous Users: |
|
Up to 20 users |
| Three-Stream: |
|
Support |
| Mini SD Card: |
|
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
| User/Host Level: |
|
Up to 32 users, 3 levels: Administrator, Operator and User |
| Security Measures: |
|
User authentication (ID and PW), host authentication (MAC address) |
| Hik-Connect: |
|
Support |
| Client GUI |
| Client: |
|
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect |
| Web Browser: |
|
IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51 |
| General |
| Menu Language: |
|
English |
| Power Supply: |
|
24 VAC and PoE+ |
| Power Consumption: |
|
Max.: 30 W (Max. 10 W for IR) |
| Working Temperature/Humidity: |
|
-30 ℃-65℃(-22℉-149℉)(outdoor) 90% or less |
| Protection Level: |
|
IP66 standard (outdoor dome) TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Mounting: |
|
Various mounting modes optional |
| Material: |
|
ADC 12, PC, PC+10%GF |
| Dimensions: |
|
Φ 208 mm × 345 mm (Φ 8.19" × 13.58") |
| Weight (approx.): |
|
Approx. 3.3 kg (7.28 lb) |
