| Camera |
| Image Sensor: |
|
1/2.5" progressive scan CMOS |
| Effective Pixels: |
|
2560(H)×1440(V) |
| Signal System: |
|
PAL/NTSC |
| Minimum Illumination: |
|
Color: 0.005 Lux @(F1.6, AGC ON) B/W: 0.001 Lux @(F1.6, AGC ON) 0 Lux with IR |
| White Balance: |
|
Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| AGC: |
|
Auto/Manual |
| BLC: |
|
ON/OFF |
| HLC: |
|
Support |
| Smart defog: |
|
Support |
| WDR: |
|
120dB |
| Shutter Time: |
|
1/1 to 1/30,000s |
| Day& Night: |
|
ICR |
| Digital Zoom: |
|
16× |
| Auto Focus: |
|
Auto / Semi-automatic / Manual |
| Lens |
| Focal Length: |
|
4.8 mm to 120 mm, 25× optical |
| Zoom Speed: |
|
Approx. 3.6 s (optical lens, wide-tele) |
| Angle of View: |
|
Horizontal field of view: 59.5° to 2.6° (Wide-Tele) Vertical field of view: 35.7° to 1.5° (Wide-Tele) Diagonal field of view: 66.6 to 3.0° (Wide-Tele) |
| Minimum Working Distance: |
|
10 to 1500mm (wide-tele) |
| Aperture Range: |
|
F1.6 to F3.5 |
| Pan & Tilt |
| Pan Range: |
|
360°endless |
| Pan Speed: |
|
Configurable, from 0.1°/s to 80°/s, Preset speed: 80°/s |
| Tilt Range: |
|
-15°-90° (Auto Flip ) |
| Tilt Speed: |
|
Configurable, from 0.1°/s to 80°/s, Preset speed: 80°/s |
| Proportional Zoom: |
|
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: |
|
300 |
| Patrol: |
|
8 patrols, up to 32 presets for each patrol |
| Pattern: |
|
4 pattern scans, record time over 10 minutes for each scan |
| Power-off Memory: |
|
Support |
| Park Action: |
|
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan |
| PTZ Position Display: |
|
ON/OFF |
| Infrared |
| IR irradiation distance: |
|
100m |
| IR irradiation angle: |
|
Adjustable by zoom |
| Input & Output |
| Audio Input: |
|
1-ch audio input |
| Audio Output: |
|
1-ch audio output |
| Network |
| Ethernet: |
|
10Base -T, /100Base-TX, RJ45 Connector |
| Max.Image Resolution: |
|
2560 × 1440 |
| Main Stream: |
|
50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) 50fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) 60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub Stream: |
|
50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240) |
| Third Stream: |
|
50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288) 60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288) |
| Video Compression: |
|
Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264/MJPEG Third Stream: H.265/H.264/MJPEG |
| ROI encoding: |
|
Support 4 areas with adjustable levels |
| Audio Compression: |
|
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
| Protocols: |
|
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| No. of Simultaneous Users: |
|
Up to 20 users |
| Three-Stream: |
|
Support |
| Mini SD Card: |
|
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
| Security Measures: |
|
User Authentication (User ID and Password), Host Authentication (MAC address), HTTPS Encryption, IEEE 802.1x Port-Based Network Access control, IP address Filtering |
| Client GUI |
| Client: |
|
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect |
| General |
| Power Supply: |
|
12VDC, PoE+ |
| Power Consumption: |
|
Max.: 18W (IR light 7W Max.) |
| Working Temperature/Humidity: |
|
Outdoor: -30°C to 65°C (-22°F to 149°F) Humidity:≤ 90% |
| Protection Level: |
|
IP66 standard (outdoor dome) TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Material: |
|
ADC 12, PC+10% GF |
| Dimensions: |
|
Φ 164.5 mm × 290 mm (Φ 6.48" × 11.42") |
| Weight (approx.): |
|
Approx. 2.45kg (5.40lb) |
